01 / 03Pro Luster
PHOTO SATIN · 260 GSM
A resin-coated photo paper with a glare-killing satin sheen. Punches contrast and color depth for portfolios and exhibition prints.
PACKSHOTSPORTFOLIOSEXHIBITION PRINTS
LUCIA PRO PM / BK
CANON imagePROGRAF · STUDIO ENGINEThe PRO-4100.
The PRO-4100.
Forty-four inches of pure pigment.
Our studio press is built to exceed expectations for image quality and color consistency. A 1.28-inch-wide 12-channel integrated print head, the LUCIA PRO ink set plus Chroma Optimizer, a high-precision mechanical platform, and the L-COA PRO high-speed image-processing engine balance exceptional print quality with speed.
PRO-4100 · PRINTING
- 44"
- MAX PRINT WIDTH
- 12
- LUCIA PRO INKS + CHROMA OPTIMIZER
- 2,400 × 1,200
- DPI PRINT RESOLUTION
- 18,432
- PF-10 NOZZLES · 4 PL MIN
- ±0.1%
- LINE ACCURACY
- 500 GB
- ENCRYPTED JOB HDD
Engineered for the print, not the queue.
LUCIA PRO ink set
Microencapsulated colorants deliver smooth gradients and an expanded gamut; a dedicated Chroma Optimizer clear-coats glossy prints to even the gloss, deepen darks, and resist scratching.
No black-ink switching
Matte black and photo black run on their own dedicated nozzles — move from fine-art rag to glossy photo paper without a purge, a pause, or wasted ink.
PF-10 print head
A single 1.28-inch-wide head with 18,432 nozzles and FINE anti-clog tech. Twenty-seven sensors check ejection live; if a nozzle misfires, a backup takes over mid-print.
L-COA PRO engine
Three processing chips digest immense image data and compute the optimal ink layout in real time — high resolution without slowing the queue.
Built-in color calibration
A tri-color LED densitometer with condenser lens recalibrates color fast from the printer panel, keeping printer-to-printer differences low across supported media.
Intelligent media loading
A multi-sensor reads surface reflection and thickness to auto-detect the paper, and remaining-media estimation tracks roll length from the head — no printed barcodes.
Sub-ink tank system
Drain every drop before replacement and swap tanks on the fly — long runs never stop for ink.
Hardened job vault
A 500 GB encrypted HDD stores and reprints jobs; secure PIN printing protects work in shared environments.
Reference specification
The full Canon imagePROGRAF PRO-4100 spec sheet, transcribed for transparency — the exact machine that runs every order off the studio floor.
TECHNOLOGY
- PRINTER TYPE
- 12-colour · 44" / 1118 mm
- PRINT TECHNOLOGY
- Canon Bubblejet on-demand · 12-chip integrated print head
- PRINT RESOLUTION
- 2,400 × 1,200 dpi
- NOZZLES
- 18,432 (1,536 × 12 colours) · 600 dpi × 2 pitch
- MIN INK DROPLET
- 4 pl per colour
- LINE ACCURACY
- ±0.1% or less
- INK SET
- Pigment: Black, Matte Black, Cyan, Magenta, Yellow, Photo Cyan, Photo Magenta, Gray, Photo Gray, Red, Blue, Chroma Optimizer
- INK CAPACITY
- 160 ml · 330 ml · 700 ml
- PRINTER LANGUAGES
- SG Raster · PDF 1.7 · JPEG (JFIF 1.02)
- INTERFACES
- USB-A direct print · USB-B Hi-Speed 2.0 · Gigabit Ethernet · Wi-Fi b/g/n
MEMORY & STORAGE
- STANDARD MEMORY
- 3 GB
- HARD DRIVE
- 500 GB (encrypted)
PRINT SPEED (A0)
- PLAIN
- Fast 1:37 · Standard 2:49
- COATED
- Standard 2:49 · High Quality 5:35
- GLOSSY PHOTO
- Standard 5:35 · High Quality 8:50
MEDIA HANDLING
- ROLL / SHEET WIDTH
- 152.4–1118 mm (6"–44")
- MEDIA THICKNESS
- 0.07–0.8 mm
- MAX ROLL DIAMETER
- 170 mm
- CORE SIZE
- 2" / 3"
- ROLL FEED CAPACITY
- 2 rolls with auto-switching · 1 cut sheet
- BORDERLESS ROLL WIDTHS
- 10", 14", 17", 24", 36", 42", 44" + selected ISO/JIS sizes
- MAX PRINT LENGTH
- 18 m (roll) · 2133.6 mm (cut sheet)
DIMENSIONS & POWER
- PHYSICAL (BASKET OPEN)
- 1593 × 984 × 1168 mm
- PHYSICAL (BASKET CLOSED)
- 1593 × 766 × 1168 mm
- WEIGHT
- 145 kg (incl. roll holder & take-up unit, excl. ink/head)
- POWER
- AC 100–240 V · 50/60 Hz · ≤107 W operating · ≤2.0 W sleep · ≤0.3 W off
- ACOUSTIC NOISE
- ~48 dB(A) operating · ≤35 dB(A) standby
CONSUMABLES & OPTIONS
- INK TANKS
- PFI-1100 (160 ml) · PFI-1300 (330 ml) · PFI-1700 (700 ml)
- PRINT HEAD
- PF-10
- CUTTER BLADE
- CT-07
- MAINTENANCE CARTRIDGE
- MC-30
- ROLL HOLDERS
- RH2-46 (2" / 3")
- ROLL UNIT
- RU-43
SOURCE: CANON imagePROGRAF PRO-4100 SPECIFICATION SHEET · VALUES MIRROR THE MANUFACTURER DOCUMENT.
The paper on the roll.
Three studio stocks cover nearly every brief. Each pairs with the matching LUCIA PRO ink channel above for the deepest blacks and truest color this paper is capable of.
01 / 03
02 / 03Matte Cotton
RAG · 300 GSM
A silky matte fine-art rag with no reflective coating — matte black ink reads deep and velvety. The classic for art reproductions.
ART REPRODUCTIONSDRAWINGSLIMITED EDITIONS
LUCIA PRO MBK
03 / 03Fine Art Canvas
COTTON WEAVE · 410 GSM
A heavyweight poly-cotton canvas weave that takes the full 12-color gamut. Stretches and varnishes like a painted original.
GALLERY WRAPSSTATEMENT PIECESFRAME-ONLY RENDERING
LUCIA PRO 12-color
